Soot Probe

The soot probe is an intrusive probe that can be used to determine soot concentrations in overfire regions of large scale fires and within exhaust chimneys.

• Temperature Range: 800 K - 2600 K
• Soot Volume Fraction Range: 0.1 PPM – 50 PPM
• Response Time: < 1 ms.
• Rugged fiber-optics based probes
• Ceramic clad and water-cooled to withstand high temperatures
• Multiple Stations

• Determining soot concentrations in upper layer of large scale burns in rooms and buildings
• Estimating the opacity at different locations inside exhaust chimneys

The Soot Probe is a custom made instrument and can be tailored to a customer’s specifications. The system will include all items and software needed for data capture.

The extinction of a laser light is measured across a 50 mm gap. The extinction is converted to soot volume fractions using the refractive indices of soot.

All of En’Urga’s products are custom-made. Please provide details in the Contact Form for any modifications of performance specifications, or any change in the physical configuration of the desired instrument. A description of your application is helpful.
